Our innovative Aluminum EMT (Electrical Metallic Tubing) offers significant advantages over steel EMT. A less expensive, lighter-weight option than steel, Penn EMT provides excellent, durable and long-life wire protection in a wide range of commercial applications.
- Thin-walled and lightweight – just 1/3 the weight of steel EMT – allowing easier, faster and safer installation lightweight (just 1/3 the weight of steel EMT), for easy handling and installation
- Fast and simple cutting and bending, on the job site or in the fab shop, using standard EMT cutting and bending equipment
- Superior finished outer appearance
- Smooth internal surface from the extrusion process, with no weld line
- Connects quickly with standard EMT fittings (galvanized steel and zinc die cast fittings can be used with Aluminum EMT per the NEC handbook, section 358.14)
- 100% recyclable and non-corrosive
- Listed to UL 797A Safety Standard and in compliance with all electrical code requirements
- Meets ANSI C80.3 and Federal Specifications
- Meets the provisions of the Buy American Act
- Available in standard trade sizes ½” through 4”
- Fiberglass fish tape recommended (see all of our recommended practices here)
Aluminum Electrical Metallic Tubing (EMT) – 10′
| Penn Part Number | Trade Size | Master Bundle Pcs | Master Bundle Wt | Master Bundle Ft |
|---|---|---|---|---|
| P-012-10-EMT | 1/2″ | 700 | 721 | 7,000 |
| P-034-10-EMT | 3/4″ | 500 | 790 | 5,000 |
| P-100-10-EMT | 1″ | 300 | 699 | 3,000 |
| P-114-10-EMT | 1-1/4″ | 200 | 694 | 2,000 |
| P-112-10-EMT | 1-1/2″ | 150 | 603 | 1,500 |
| P-200-10-EMT | 2″ | 120 | 614 | 1,200 |
| P-212-10-EMT | 2-1/2″ | 61 | 455 | 610 |
| P-300-10-EMT | 3″ | 51 | 465 | 510 |
| P-312-10-EMT | 3-1/2″ | 37 | 444 | 370 |
| P-400-10-EMT | 4″ | 30 | 407 | 300 |
